안테나
pmf

Selectable
Methods

Selectable optimal transmission
methods for various requirements

Specifications

  • Data rate

    : Up to 10 Gbps
    Jitter < 0.35 UI @ 27-1 PRBS)

  • Modulation

    : Low-power ASK

  • Input/output port

    : Differential SLVS(NRZ)

  • Total link budget

    : 24 dB

  • Supply voltage

    : 1.8V and 1.0V supply

  • Power consumption

    : 120mW in TX mode
    87.5mW in RX mode

  • Supporting configuration

    : Using I2C bus

  • Operating temperature

    : -20 to 85℃

  • Size

    : FCBGA 3.5mm x 3.5mm x 0.8mm,
    25pin BGA, 0.65mm pitch
product-protocol
High-speed
Data transfer

Max 10Gbps + @

Clean
Signal Quality

Total Jitter 0.35 UI

Multiple
Protocols

Multi-Protocol

Applications

For your creativity and signal integrity,
we develop and provide

Hard IP
Custom IC
Custom Module
