Supporting interfaces

Gigabit Ethernet / USB / MIPI / UART / GPIO / SPI / I2C / CAN / RS232 / SPE

Key features

Antenna

Up to 2m

Plastic waveguide

meter level

  • Frequency Band & Data Rate
  • - Global-unlicensed band 60GHz & Up to 6.25Gbps
  • Power Supply
  • - Supply voltage: 1.8V (single supply)
  • Power Consumption
  • - TX Mode: 147 mW
  • - RX Mode: 101 mW
  • - Stand-by Mode (system clock ON): < 6mW
  • Operating Temperature
  • - Commercial grade: -20°C to +85°C
  • - Industrial grade: -40°C to +105°C
  • Package
  • - FCCSP 3.5mm x 3.5mm x 0.94mm
  • - 36 balls, 0.55mm pitch
  • Additional Features
  • - RSSI (Received Signal Strength Indicator)
  • - OPRC (OTA-based Pairing IC Register Control)
  • - Full-duplex support for UART, SPI, USB and Ethernet
  • - Fixed hardwire Mode without External MCU control
